HDR Scopes Specs

---

SDI

• Single Link SDI/HD-SDI 4:2:2 8/10 bit
• Dual Link HD-SDI 4:4:4 10/12 bit
• Dual Link HD-SDI 4:4:4:4 10 bit
• Quad Link HD-SDI (Quad HD and 4K) 4:2:2 or 4:4:4 8/10/12 bit
• 3G/6G Dual Link HD-SDI 4:4:4 10/12 bit
• 3G/6G Dual Link HD-SDI 4:4:4:4 10 bit
• 3G/6G Dual Rate SDI/HD-SDI 4:2:2 8/10 bit
• 12G QHD/4K Quad Link and 2SI 12G (sample interleave)
• 12G x 4 SUHD/8K 2SI
• CCIR-601 (SD), Rec.709 (HD), BT.2020 (WCG), P3 or Rec.709 (QHD/4K)
• HDR (High Dynamic Range) as ST2084/PQ/HDR10 or HLG

HDMI

• HDMI (1.4 or 2.0+, hardware dependent)

NDI

• NewTek NDI® - (Network Device Interface) Any NDI audio/video source

Adobe/Avid

• AJA shared mode (requires AJA board)
• ScopeDirect - receive audio/video from application running on the same machine
• ScopeDirect Transmitter (Adobe)
• ScopeDirect OpenIO (Avid)
• Adobe/Avid NDI

Desktop

• View your desktop through scopes

Sync

• Reference video sync (Blackburst or Tri-Level, hardware dependent)

• NewTek NDI®
• Embedded audio, up to 16 channels 24 bit
• Analog inputs, up to 16 channels 16/24 bit
• AES/EBU audio, up to 16 channels 24 bit

• Main output (computer monitor) from HD up to 8K
• Secondary down converted output available
• SD/HD/2K down conversion to HDMI and analog
• HDMI 4K/8K quadrant output
• Available in monitor HDR -> SDR picture conversion

• SD - PAL/NTSC
• 720P - 23 / 24 / 25 / 29 / 30 / 50 / 59 / 60
• 1080i - 23 / 24 / 25 / 29 / 30
• 1080PsF - 23 / 24 / 25 / 29 / 30
• 1080P - 23 / 24 / 25 / 29 / 30 / 50 / 59 / 60
• 2K Digital Cinema (2048 x 1080) - 23 / 24 / 25
• 2K Film (2048 x 1556) - 14 / 15 / 23 / 24
• UltraHD/UHD (3840 x 2160) - 23 / 24 / 29 / 30 / 50 / 59 / 60
• 4K (4096 x 2160) - 23 / 24 / 29 / 30 / 50 / 59 / 60
• SUHD (7680 x 4320) - 23 / 24 / 29 / 30 / 50 / 60
• 8K (8192 x 4320) - 23 / 24 / 29 / 30 / 50 / 60

8K/SUHD/4K/QHD/HD/SD Processing Modes:

• YCbCr 8 bit 4:2:2
• YCbCr 10 bit 4:2:2 (standard single link)
• YCbCr 12 bit 4:4:4 (dual link or 3G/6G/12G)
• RGB 8 and 10 bit 4:4:4:4
• RGB 10 and 12 bit 4:4:4 (standard dual link or 3G/6G/12G)

• LTC/SMPTE analog time code and user bits
• VITC/D-VITC vertical blank time code and user bits
• RP-188 HANC time code and user bits
• RP-215 VANC time code, user bits, key code and ink code
• Active Format Description detection
• DID/SDID detection and highlighting

For 8K/SUHD

• AJA:  KONA 5G

For 4K/QHS/HD/SD

• AJA:  KONA 5G
• Please see 4KScope for a full list of supported 4K-SD hardware
